| Steel Silencers |
|
Steel Bolt-On Silencers
|
Want to quiet your race pipes? These bolt-on silencers mount
with a clamp to your stinger. The core O.D. is the same size as
the stinger you mount it on.
| 7" - 1 2.25" Body |
SIL14804 |
| 7" - 1 1/8" 2.25" Body |
SIL14805 |
| 7" - 1 1/4" 2.25" Body |
SIL14806 |
| 9" - 1 3/8" 3.00" Body |
SIL14815 |
| 4" - 1" 2.25" Body |
SIL14495 |
| 4" - 1 1/8" 2.25" Body |
SIL14496 |
| 4" - 1 1/4" 2.25" Body |
SIL14497 |
| 4" - 1 3/8" 2.25" Body |
SIL14498 |
|
|
|
| Aluminum Silencers |
|
Rebuildable Racing Silencers
|
We developed these silencers to meet the new I.R.S. race
silencer rules. This fiber-packed silencer has the required 6"
core length and a lightweight 2.25" aluminum body. A steel end
cap is fastened with 3 screws to make it quickly rebuildable.
The steel end clamp can be clamped or welded to the stinger. The
silencers are sized to fit over the O.D. of your stinger. The
core will then match the O.D. of your stinger pipe. Shorten your
stinger pipe 6" when mounting to obtain correct flow and tuning
length.
|
| 7" - 1" - 2.25" Body |
SIL14501 |
| 7" - 1 1/8" 2.25" Body |
SIL14502 |
| 7" - 1 1/4" 2.25" Body |
SIL14506 |
|
|
|
3" Aluminum Silencers
|
These larger 3" rebuildable aluminum silencers can be used on
larger twin pipes or on a single torquer pipes. Silencers are
available in 1-1/4, 1-3/8 and 1-1/2 core size.
|
| 9" - 1-1/4" 3.00" Body |
SIL14510 |
| 9" - 1 3/8" 3.00" Body |
SIL14507 |
| 9" - 1 1/2" 3.00" Body |
SIL14817 |
|
|
|
| Repacking Kit |
|
Enough of our best strand, high density silencing material to
pack two 2.25" silencers.
|
|
| Perforated Cores |
Silencers and cores are classified and sold according to the
outside diameter of the core. Cores have a .050" wall. To find
the I.D. of the core, check the table below.
Core size
inches |
Part Number |
O.D.
inches |
I.D.
inches |
| 1" |
SIL14523 |
1.000" |
.900" |
| 1-1/8" |
SIL14524 |
1.125" |
1.025" |
| 1-1/4" |
SIL14525 |
1.250" |
1.150" |
| 1-3/8" |
SIL14526 |
1.375" |
1.275" |
|
Please ask if you are not sure. You are responsible if
cores and silencers are ordered incorrectly You will pay
all shipping and restocking fees.
|
|
|
|
| Exhaust Gaskets |
|
| Universal Gasket |
EXH14534 |
|
|
| Double Seal Flange |
A radiused edge matches the inside of the flange to allow
movement, while a piston ring takes care of the secondary
sealing.
|
| Single Seal Kit |
EXH12998 |
| Flange Only (no ring) |
EXH14541 |
| Double Seal Ring (1) |
EXH13016 |
| Double Seal Cup |
EXH14510 |
|
|
|
| Flanges and Cups |
Whether you want to replace a cup that is worn out, or you are
building your own pipes, we have an assortment of cups
available. We also offer a universal flange which fits on most
snowmobile models. When replacing a cup on an Aaen pipe, be
prepared to provide us with the year, make and model of your
machine.
|
| Polaris S.P, Lg Cup |
EXH14790 |
| Polaris, Yamaha PZ Cup |
EXH14538 |
| Arctic Old Style |
EXH14511 |
| Arctic New Style |
EXH14512 |
| 2" ACS Ball Coupler |
EXH14513 |
| Universal Blank Flange |
EXH14514 |
|
|
| U Bends and Tubing |
Fitting your own pipes? U-Bends priced per piece, straight tubes
priced per 3 ft length.
|
| U-Bends (priced per piece) |
|
| 2" O.D. 4" Radius |
EXH14515 |
| 1-7/8" O.D. 4" Radius |
EXH14516 |
|
1-1/4" O.D. 2.5" Radius
|
EXH14517 |
| 1-1/2" O.D. 3" Radius |
EXH14523 |
| 1-5/8" O.D. 3" Radius |
EXH14524 |
| 1-3/8" O.D. 3" Radius |
EXH14525 |
|
|
Tubing (priced per 3 foot section)
|
|
| 1" Tubing .050 Wall |
EXH14518 |
|
1-1/8" Tube .050 Wall
|
EXH14519 |
|
1-1/4" Tube .050 Wall
|
EXH14520 |
|
1-3/8" Tube .050 Wall
|
EXH14521 |
|
1-1/2" Tube .050 Wall
|
EXH14522 |
|
|
|
| Springs and tabs |
Installation springs and Tabs.
|
| Springs, Ten per kit |
EXH13040 |
| Springs Tabs, Ten per kit |
EXH13041 |
| Spring Puller Tool |
EXH14539 |
|
|
| Heat Insulation |
| Heat Wrap |
|
Contains no asbestos, insulates better than ceramic coating and
protects against shock cooling by snow dust that can result in
cracked pipes. Secure with Snap Strap and spray with High Heat
Barrier to prevent deterioration with the wrap. Roll is 50' X 2"
X 1/16", wraps 2 pipes.
|
|
| Snap Strap |
|
Stainless steel tie wraps. Easier than conventional hose clamps.
Kit contains 20 ft. of strap and 20 clips.
|
|
| High Heat Barrier |
|
Made by ThermoTec to protect the heat wrap from damage by fluids
and flying debris.
|
|
